Our Finix RRS Coupling, also known as Radially Removable Spacer-Type (RRS) Coupling is ideal for a wide range of end suction back pull-out pumps. It is constructed to meet the top industry standards for pump and motor shaft separations, and the spacer can be made from materials including glass-reinforced plastic, cast iron, or aluminum.
Finix RRS Couplings are optimized for general engineering applications that demand dependable power transmission, even in situations where shaft misalignment occurs, which is frequently inevitable.
Our extensive range of advanced RRS coupling offers outstanding efficiency and consistent performance. Manglam Engineers is committed to delivering superior quality and exceptional durability in the RRS Couplings.
Detail Drawing of RRS Coupling
Working Principle of RRS Coupling
| Technical Specification - RRS Coupling | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| Size | Rated Torque Nm | Kw Rating at 100 RPM | Min. Bore | Max. Bore | Spacer Length Distance Between Shaft Ends (DBSE) A | Boss Dia OD H | Spacer OD D | Adaptor Body Length C | Gap E |
| RRS 095 | 21 | 0.22 | 10 | 24 | 90, 100, 140, 180 | 49 | 64 | 25 | 2 |
| RRS 100 | 46 | 0.49 | 10 | 28 | 57 | 78 | 35 | 2 | |
| RRS 110 | 89 | 0.93 | 15 | 38 | 76 | 96 | 43 | 3 | |
| RRS 150 | 141 | 1.49 | 15 | 42 | 80 | 111 | 45 | 3 | |
| RRS 190 | 190 | 2.01 | 20 | 50 | 102 | 130 | 54 | 3 | |
| RRS 225 | 265 | 2.76 | 20 | 55 | 111 | 142 | 64 | 3 | |
| RRS 226 | 327 | 3.43 | 25 | 65 | 115 | 153 | 70 | 3 | |
RRS Coupling Features
- Straight Visual Inspection
- Reduced Moments of Inertia
- Enhanced Misalignment Tolerance
- Lower Inventory Costs
- Easily Removable & Replaceable
- Less Downtime
Solving Power Transmission Challenges in the Industry
Why Our Product?
Quality Assurance
Customer Satisfaction
Industry Expertise
Excellence
Application of RRS Coupling
Product Video
- Range: 50 mm to 160 mm
Leading Exporter of Transmission Couplings & Industrial Rubber Parts
From our advanced manufacturing hub to your factory floor, Manglam Engineers delivers precision and quality. As a globally recognized manufacturer and exporter, we specialize in Transmission Couplings and a wide range of Industrial Rubber Parts. We empower key sectors such as Industrial Pumps Manufacturer, Automotive, Agriculture, Chemical, Water Solutions, Mining, and General Manufacturing, exporting our precision components to Germany, United States, United Kingdom, China, UAE, Indonesia, and Sri Lanka.
Our success is driven by a commitment to innovation, quality, and our customers. We don't just sell parts; we build lasting partnerships. Experience the Manglam Engineers difference and let us be a part of your global success story.
